Gateway FPD1830 Service Manual

- 21 -
DATE: 2002. 08. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1 0CH8106F691 10UF 16V 20% 105STD (CYL) R/TP
C106 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C107 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C151 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C160 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C161 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C201 0CH3103K516 10000PF 50V K B 2012 R/TP
C202 0CH3103K516 10000PF 50V K B 2012 R/TP
C203 0CH3103K516 10000PF 50V K B 2012 R/TP
C204 0CH3103K516 10000PF 50V K B 2012 R/TP
C205 0CH3103K516 10000PF 50V K B 2012 R/TP
C206 0CH3103K516 10000PF 50V K B 2012 R/TP
C207 0CH3103K516 10000PF 50V K B 2012 R/TP
C208 0CH3103K516 10000PF 50V K B 2012 R/TP
C209 0CH3103K516 10000PF 50V K B 2012 R/TP
C210 0CH3103K516 10000PF 50V K B 2012 R/TP
C211 0CH3103K516 10000PF 50V K B 2012 R/TP
C212 0CH3103K516 10000PF 50V K B 2012 R/TP
C213 0CH3103K516 10000PF 50V K B 2012 R/TP
C214 0CH3103K516 10000PF 50V K B 2012 R/TP
C215 0CH3103K516 10000PF 50V K B 2012 R/TP
C216 0CH3103K516 10000PF 50V K B 2012 R/TP
C217 0CH3103K516 10000PF 50V K B 2012 R/TP
C218 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C219 0CH3103K516 10000PF 50V K B 2012 R/TP
C220 0CH6330K416 33PF 50V J NP0 2012 R/TP
C221 0CH6330K416 33PF 50V J NP0 2012 R/TP
C222 0CH3103K516 10000PF 50V K B 2012 R/TP
C223 0CH3103K516 10000PF 50V K B 2012 R/TP
C224 0CH3103K516 10000PF 50V K B 2012 R/TP
C225 0CH3103K516 10000PF 50V K B 2012 R/TP
C226 0CH3103K516 10000PF 50V K B 2012 R/TP
C227 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C228 0CH3103K516 10000PF 50V K B 2012 R/TP
C229 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C230 0CH6150K416 15PF 50V J NP0 2012 R/TP
C231 0CH6680K416 68PF 50V J NP0 2012 R/TP
C232 0CH6680K416 68PF 50V J NP0 2012 R/TP
C233 0CH3103K516 10000PF 50V K B 2012 R/TP
C234 0CH3103K516 10000PF 50V K B 2012 R/TP
C235 0CH6680K416 68PF 50V J NP0 2012 R/TP
C236 0CH6680K416 68PF 50V J NP0 2012 R/TP
C237 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C258 0CH6150K416 15PF 50V J NP0 2012 R/TP
C259 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C260 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C261 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C262 0CH6330K416 33PF 50V J NP0 2012 R/TP
C264 0CH6221K416 220PF 50V J NP0 2012 R/TP
C265 0CH6470K416 47PF 50V 5% NP0 2012 R/TP
C269 0CH3103K516 10000PF 50V K B 2012 R/TP
C270 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
DATE: 2002. 08. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C271 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C272 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C273 0CH3103K516 10000PF 50V K B 2012 R/TP
C274 0CH3103K516 10000PF 50V K B 2012 R/TP
C275 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C276 0CH3103K516 10000PF 50V K B 2012 R/TP
C278 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C279 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C280 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C301 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C302 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C303 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C304 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C305 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C306 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C307 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C308 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C309 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C310 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C311 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C312 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C313 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C314 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C315 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C316 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C317 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C318 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C401 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C402 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C403 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C404 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C405 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C406 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C407 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C408 0CH8226F691 22UF 16V 20% 105STD (CYL) R/TP
C409 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C410 0CH8226F691 22UF 16V 20% 105STD (CYL) R/TP
C411 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C412 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C413 0CH8226F691 22UF 16V 20% 105STD (CYL) R/TP
C501 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C502 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C503 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C504 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C505 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C506 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C507 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C508 0CK222CK51A 2200PF 1608 50V 10% R/TP B(Y5P
C510 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C511 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C513 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C514 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C515 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C516 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
