Gateway FPD1830 Service Manual

DATE: 2002. 08. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C517 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C519 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C520 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C521 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C522 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C526 0CH8106J691 10UF 35V 20% 105STD (CYL) R/TP
C531 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C532 0CH8106J691 10UF 35V 20% 105STD (CYL) R/TP
C533 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C548 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C701 0CE477EH618 470UF KMG 25V M FL TP 5
C706 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C707 0CH8106J691 10UF 35V 20% 105STD (CYL) R/TP
C710 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C714 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C715 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C727 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C728 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C729 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C730 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C731 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C738 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C740 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C817 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C818 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C819 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C820 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C822 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C823 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C824 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C825 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C826 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C827 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C828 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C829 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C830 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C831 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C832 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C833 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C834 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C835 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C836 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C840 0CE477EH618 470UF KMG 25V M FL TP 5
C843 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C844 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C845 0CE477EH618 470UF KMG 25V M FL TP 5
C850 0CE477EH618 470UF KMG 25V M FL TP 5
C860 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C870 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C871 0CH6101K416 100PF 50V J NP0 2012 R/TP
C872 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C873 0CH6101K416 100PF 50V J NP0 2012 R/TP
D501 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D502 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D503 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D504 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D703 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
DATE: 2002. 08. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D704 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D730 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D731 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D732 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D733 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D734 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D735 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D736 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D737 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D738 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D739 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D740 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D741 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D742 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D743 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D744 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D745 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D746 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D747 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D903 0DRIR00011B 16CTQ100 I.R ST TO220 100V 16A
D906 0DRIR00021A 30CTQ060 I.R ST TO220 60V 30A
ZD701 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD702 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD703 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD704 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD705 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD711 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD721 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD722 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
U105 0ITI741400T SN74AC14DR 14,SOP R/TP HEX INV
U110 0ISS780500H KA78M05-R 3P,D-PAK TP 5V 0.5A
U201 0IPRPGN001A GM5020 GENESIS 292P,PBGA TRAY
U301 0IEB121616A M12L16161A-7T 50P TSOP ST 16M(
U302 0IEB121616A M12L16161A-7T 50P TSOP ST 16M(
U303 0IEB121616A M12L16161A-7T 50P TSOP ST 16M(
U401 0ILNRTH001A THC63LVD823 THINE MICROSYSTEMS
U501 0IZZTSZ202A BD48 42PIN BK MICOM
U503 0ICS240813B CAT24WC08J-TE13 8P,SOIC R/TP 8
U504 0ISS524202B S524A40X21(SCT0) SAMSUNG ELECT
U509 0ISS524202B S524A40X21(SCT0) SAMSUNG ELECT
U802 0TFFC80009A FAIRCHILD FDC6326L R/TP SOT-6
U803 0IPMGFA003B RC1117S-2.5 FAIRCHILD SOT-223
U820 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
U821 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
L202 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L203 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L204 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L205 6210TCE001R HB-1S2012-400JT CERATECH 2012M
L206 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L207 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L401 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L402 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L403 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L703 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L704 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L804 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
- 22 -
DIODEs
ICs
COILs & COREs
