DATE: 2002. 08. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
TH902 6322TA080AA TP8D13 DAEWOO +/- 15% 110/220
ZD901 0DZ470009BC GDZ4.7B TP GRANDE DO34 0.5W 4.
C1 0CN1040K949 0.1M 50V Z F TA52
C2 0CN1040K949 0.1M 50V Z F TA52
C3 0CN1040K949 0.1M 50V Z F TA52
J1 6602T20009E SMAW200-06 YEONHO 2.0MM LOCK R
J2 971-0054 TIN 50MM TAPING
LED1 0DL305029BA LTL-305DJ-0C2 TP LITEON GREEN/
R1 0RD4701Q609 4.70K 1/4W(3 5% TA52
R2 0RD4701Q609 4.70K 1/4W(3 5% TA52
R3 0RD8200Q609 820 1/4W(3 5% TA52
R4 0RD8200Q609 820 1/4W(3 5% TA52
R5 0RD1501Q609 1.50K 1/4W(3 5% TA52
R6 0RD1501Q609 1.50K 1/4W(3 5% TA52
R7 0RD2201Q609 2.20K 1/4W(3 5% TA52
SW1 140-058D SKHV10911A LGEC NON 12 20 HORI
SW2 140-058D SKHV10911A LGEC NON 12 20 HORI
SW3 140-058D SKHV10911A LGEC NON 12 20 HORI
SW4 140-058D SKHV10911A LGEC NON 12 20 HORI
SW5 140-058D SKHV10911A LGEC NON 12 20 HORI
SW6 140-058D SKHV10911A LGEC NON 12 20 HORI
SW7 140-058E SKHV10910B LGEC NON 12V 20A HO
ZD1 0DZ560009CE MTZJ5.6B TP ROHM-K DO34 500MW
ZD2 0DZ560009CE MTZJ5.6B TP ROHM-K DO34 500MW
- 25 -
CONTROL BOARD
