Getting to know your computer - 11
BASE VIEW
1
2
3
4
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch
Releases the battery for removal. Insert a
suitable tool and slide to release.
3
Memory
compartment
Houses the computer's main memory.
Hard disk bay
Houses the computer's hard disk (secured with
screws).
4
Ventilation and
cooling fan
Allows the computer to stay cool.
- Do not cover or obstruct the openings.
