PY800AC/PY1400AC SLIDING GATE OPERATOR
11
Motor and capacitor (Terminal X2, X3): V (com), U (Positive direction), W
(Opposite direction), E (grounding), C (capacitor)
Control board
CC
Capacitor
Terminal X3
W
U
V
Motor
W
V
UE
Terminal X2
Fig.11
7.
7.
7.
7. Tuning
Tuning
Tuning
Tuning and
and
and
and operation
operation
operation
operation
Remote control
� The remote control works in a single channel mode. It has four
buttons. See Fig.12 Remote transmitter (only one type) . The function
of button 1, button 2 、 button3 and button 4 are the same. With each
press of the remote control button which has been programmed, the
gate will close, stop, open or stop cycle.
� You can program/learn button 1, button 2, and button 3 individually.
You also can program/learn two buttons or three buttons together, but
you need repeat the program/learn process if you want to use more
than one button.
