P.3
O3 x 12
M2 x 5
M2 Nut
M3 x 4
將腳架置入馬達艙內並鎖上螺絲。
將馬達套入馬達艙內並鎖上螺絲。
機身製作
機身製作
腳架
Main Frame Assembly
Insert the spring type landing gear into motor base, tighten with screws as drawing indicates.
Insert the motor into the motor base and tighten with screws (M3 x 4) as drawing indicates.
Main Frame Assembly
Spring type landing gear.
