10
General Installation Guidelines
• Before any initial step you do, read carefully this installation guide. Keep it
for future use.
• After opening the product’s package, make sure the device is in a good
condition, and there is no breakage visible. If you have any doubt about
the product’s integrity, please contact Gauzy’s support center.
• Before connecting the device for the first time, make sure the voltage and
frequency of your AC network match the electrical specification of this
unit.
• Before connecting this unit to the
, make sure this controller model
matches the
electrical specification requirements.
• Proper use of this device requires connecting the AC input GROUND
terminal to earth.
• The electrical connections of this device must be made by a
qualified electrician.
• This device was designed to work for the purposes it was designed
for. Connecting this device to other type of load rather than
may damage the device. Gauzy Ltd. Will not be responsible for any
damaged cause by inappropriate usage of this device.
• This device is for indoors use only.
• This device is to be used in a permanent connection.
The following table describes the wires and conductors that must be used for
the installation
AC Input & HV Controls At least 1mm
2
/16AWG Conductors rated for 110/220 VAC
Dry Contacts LV Controls 18 - 24AWG wires. Preferred solid conductors
AC OUT (Connection to
) At least 0.2mm
2
/24AWG conductors (*)
(*) – Conductor thickness depends on the total area of connected and
the distance of the
to the controller
• The connection of the controller to the electrical cabinet always should
be done through a circuit breaker with a rating of 6-10A type B
• The device is suitable for wall mounting, or to be installed inside an
electrical cabinet.
• The installation should always allow enough place for natural ventilation
of the unit.
• Never leave wire conductors exposed. If needed use isolation tape to
cover the unit’s terminals
