GBD AS07200 - WARNING Leds

IT ITUK
SR302
19
UK
SR302
18
10 - WARNING LEDs
DL1
RED
DIP 1
It is on when the relevant DIP is in ON
DL2
RED
DIP 2
DL3
RED
DIP 3
DL4
RED
DIP 4
DL9
BLUE
INFO
The control unit is at rest
0,5s ON
The control unit is storing the transmitter.
The control unit is storing the pause time
DL5
RED
DIP 5
DL6
RED
DIP 5
DL7
RED
DIP 7
DL8
RED
DIP 8
0,2s ON 2s OFF
1s ON - 1s OFF - 1s ON
It is on when you push SW2 button to store a new transmitter or
cancel all the transmitters.
DL10
RED
The control unit has stored the transmitter
0,7s OFF- 0,7s ON
0,7s OFF - 0.7s ON
0,7s OFF - 10s ON
The cancellation of all transmitters has been successfully
completed
RX
0,5s OFF - 0,5s ON - x10
- 1s OFF - 1s ON
0,5s OFF - 0,5s ON - x4
- 1s OFF - 1s ON
The radio receiver memory is saturated, it is not possible to
store new transmitters
DescriptionPosition
Colour
Signal
! Remove power to the control unit
! Push and keep pushing Sw2 button;
! Power the control unit;
! Wait for no. 3 acoustic signals;
! Release the SW2 button
! Reset completed, working and pause times have been set to default values.
11 - OF WORKING AND PAUSE TIMES
UE Declaration of conformity
The manufacturer
declares that the product
ELECTRONIC CONTROL UNIT SR302 AS07200
is in conformity with the following Directives
•
and that the following harmonised standards have been applied
•
•
•
•
•
:
GI.BI.DI.
Via Abetone Brennero, 177/B,
46025 Poggio Rusco (MN) ITALY
:
:
•
:
•
•
Date 08/07/2021
S.r.l.
2014/53/UE;
2011/65/UE
301 489-1 V2.2.0;
N 301 489-3 V2.1.1;
300 220-2 V3.2.1;
2479:2010;
0950-1:2014;
EN
E
EN
EN 6
EN6
EN60335-1,
EN61000-6-2, EN61000-6-3
The Legal Representative
Michele Prandi
UKCA manufacturer declaration:
The UKCA declaration is available at http://conformity.gibidi.com
