REVERSING THE DOOR SWING (CONT.)
Installation Instructions
TRANSFER BOTTOM HINGE TO
THE LEFT
Remove the bottom hinge, screws and shim(s) from
the right side and reassemble them on the left side of
the cabinet.
ATTENTION: The screws must be properly
tightened. Turn the screws until snug. Then
tighten the screws a minimum of one full turn
using both hands.
4
TRANSFER CENTER HINGE TO
THE LEFT
Remove the two screws on the opposite side.
5
Remove the center hinge, shim and screw(s).
Reassemble the center hinge on the left side.
CAUTION: When assembled correctly, the hinge
is tight against the cabinet.
ATTENTION: The screws must be properly
tightened. Turn the screws until snug. Then
tighten the screws a minimum of 1/2 turn using
both hands.
