GE 12 Owner's Manual And Installation Instructions

13
Installation Instructions
REHANG THE FRESH
FOOD DOOR
Make sure the washer(s) are in place on the bottom
hinge pin. Place the fresh food door on the bottom
hinge and position it under the center hinge. Drop
the hinge pin into the center hinge to hold the door
in place and tighten the screw.
9
REHANG THE FREEZER DOOR
10
Place the washer(s) on the center hinge pin. Place
the freezer door on the center hinge over the pin.
Raise the top hinge by hand and insert the pivot
pin into the hole in the door. Then swing the
door shut.
ALIGN THE DOORS
11
Align the freezer door with the fresh food door so
that the gap between the doors is even.
Tighten the top hinge screws by turning them until
snug. Then turn the screws a minimum of 1/2 turn
using both hands.

GE 12 Specifications

General

Type	Top Freezer Refrigerator
Brand	GE
Model	GE 12
Category	Refrigerator
Color	White
Door Hinge	Reversible
Capacity	12 cu ft
Shelves	2
