3 SETUP AND USE
g
GE Power Management
31
Table 3-2 Actual Values
3$*( /,1( '(6&5,37,21
11
PAGE 1: ACTUAL VALUES
PHASE CURRENT DATA
ACTUAL VALUES page 1 header.
12
MOTOR STARTING
###1###2###3###4###5###6
Motor starting current level (seen only during a motor start).
13
I1= XXXX I2= XXXX
I3= XXXX (AMPS) ---
Motor phase current data. ("---" becomes "RUN" when motor is running).
14
I(3 ph avg) = XXXX AMPS
Max Stator RTD = XXX C
Average of 3 phase currents. Maximum of 6 stator RTDs.
15
UNBALANCE RATIO (In/Ip)
U/B = XXX PERCENT
Ratio of negative to positive sequence currents.
16
GROUND FAULT CURRENT
G/F = XX.X AMPS
Actual ground fault current.
17
END OF PAGE ONE
ACTUAL VALUES
Last line of page 1.
