PAGE 3: ACTUAL VALUES
MOTOR CAPACITY DATA
ACTUAL VALUES page 3 header.
32
ESTIMATED TIME TO
TRIP = XXX SECONDS
Estimated time to overload trip under present conditions (seen only during overloads).
33
MOTOR LOAD AS A PERCENT
FULL LOAD = XXX PERCENT
Actual motor current as a percentage of full load.
34
THERMAL CAPACITY
USED = XXX PERCENT
Percentage of motor thermal capacity used.
35
END OF PAGE THREE
ACTUAL VALUES
Last line of page 3.
