1. Spray nozzle
2. Fill inlet cover
3. Fill inlet
4. Function knob
Turn right : steam ironing
Turn left : dry ironing
Press to open fill inlet cover (2)
5. Spray
button
6. Steam burst button
7. Fabric setting button with display
8. Handle
9. Swivel cord guard
10. Heel
11. Power cord with power plug and tie
12. Water reservoir
13. Color-changing indicator
14. Soleplate with steam nozzles
15. Measuring cup
4
5 6 7
1
2
3
15 13 1214
8 9
10
11
