Fresh Food Compartment
Unplug the refrigerator.
Pull off the temperature control knobs.
Pull bottom of light shield down and
forward, then rotate the top up and off.
After replacing with an appliance bulb of the
same or lower wattage, reinstall the light shield,
replace temperature control knobs and plug the
refrigerator back in.
3
2
1
Freezer Compartment
Unplug the refrigerator.
Remove the shelf just below light shield.
(The shelf will be easier to remove if it is
emptied first.)
Pull the light shield toward you to reach
the bulb.
After replacing with an appliance bulb of the
same or lower wattage, reinstall the shield
and shelf and plug the refrigerator back in.
3
2
1
13
Replacing the light bulbs.
Turning the control to the (off) position does not remove power to the light circuit.
