15
About the automatic icemaker. (cont) GEAppliances.com
Removing Ice Bin (dispenser models)
CAUTION: The ice bin is heavy when full.
Set the power switch to the OFF position before removing the
bin.
When replacing the bin, be sure to press it firmly into place. If
it does not go all the way back, remove it and rotate the drive
mechanism 1/4 turn. Then push the bin back again.
Rotate
Drive
Mechanism
Dispenser Models only
Lift the bin, then pull it forward
until the bin stops.
Lower the bin to access ice or
reach the power switch.
Models with tilt out ice bin
To access ice and reach the icemaker power switch:
Accessing Ice and Reaching the Power Switch on
Dispenser Models
There are two types of ice storage bins on dispenser models.
One has a shelf above the bin, the other does not.
Special note for models with tilt-out ice bin:
These models have a tilt-out ice bin. The bin can be tilted
out as shown in the illustrations, and it will hold itself up
while you take ice out or turn the icemaker power switch
RQDQGRȺ%HVXUHWRSXWWKHELQEDFNLQSODFHEHIRUH
closing the door.
NOTE: ,QRUGHUWRWDNHIXOODGYDQWDJHRIWKHWLOWRXWLFHELQRQO\
store items on the shelf below the ice bin that are no taller than the
lowest point on the bin.
To access ice, pull the bin forward.
To reach the power switch, pull the
shelf straight out. Always be sure to
replace the shelf.
Models with a shelf above the ice bin
Shelf
Ice Bin
Shelf
Ice Bin
Pull the bin forward until the
bin stops.
Lower the bin to access ice or
reach the power switch.
On some models, to access ice or reach the power switch:
