27
Installation Instructions
MOVING THE REFRIGERATOR (CONT.)
REMOVE THE FREEZER DOOR (cont.)
As one person slowly lifts the freezer door up
DQGRȺWKHERWWRPKLQJHWKHVHFRQGSHUVRQ
should carefully guide the water line and power
line (harness) through the bottom hinge.
Set the door on a non-scratching surface with
the inside up.
7
D
E
90°
REMOVE THE REFRIGERATOR DOOR
Remove the refrigerator door top hinge cover
(if equipped) by either squeezing it and pulling it
XSRUE\SU\LQJLWRȺZLWKDSODVWLFSXWW\NQLIH
8
A
REMOVE THE REFRIGERATOR DOOR
(cont.)
5HPRYHWKHWZRµRUµKH[KHDGVFUHZV
then lift the hinge straight up to free the hinge
pin.
Open the refrigerator door to 90.°
8
B
C
µRUµKH[KHDG
90°
To Next Page
