Freezer Shelves and Baskets
A shelf above the ice storage bin
A half-width basket
A shallow full-width basket
A deep full-width basket
NOTE: Do not fill baskets higher than the rim of
the basket. This may cause baskets to stick or
jam when opening or closing.
Basket Removal
To remove the shallow full-width basket:
Pull the basket out to the stop location.
Lift the front up and over the stop location.
Lift the basket up and out.
To remove the deep full-width basket on
freezer drawer models:
Open the freezer drawer until it stops.
The freezer basket rests on the inside tabs
on the drawer slides.
Lift the basket so that it is out of all 6 slide
bracket tabs.
Tilt the basket and lift out of the drawer.
When replacing the deep full-width basket:
Tilt the basket back and lower it down into
the drawer. Rotate the basket to a horizontal
position and press it down into the 6 alignment
tabs.
NOTE: Always be sure that the basket is seated
in all 6 slide bracket tabs before sliding back
into the freezer. The basket can be turned in
either direction front to back and installed into
the freezer.
To remove the half-width basket:
Pull the basket out to the stop location.
Lift the basket up at the front to release it
from the slides.
Lift the back up and out of the slide.
When replacing the basket, make sure that
the wire tabs and wire hooks on the sides of the
basket go into the slots in the top of the upper
basket slides.
NOTE: Always be sure to fully close this basket.
About the freezer. GEAppliances.com
Not all features are on all models.
Appearance and features may vary
Appearance may vary
Appearance may vary
Appearance may vary
11
