GE 23

73
Installation Instructions
29 27 25 / 26 23
A* 1733 mm 1733 mm 1733 mm 1733 mm
B
908 mm 908 mm 908 mm 908 mm
C** 912 mm 879 mm 879 mm 738 mm
D
1261 mm 1271 mm 1271 mm 1156 mm
E
1273 mm 1255 mm 1247 mm 1232 mm
F 1051 mm 1093 mm 1099 mm 989 mm
G
1386 mm 1381 mm 1381 mm 1361 mm
H 1140 mm 1150 mm 1149 mm 1023 mm
*
The height does not include hinges.
**The depth includes handles.
DIMENSIONS
23´ 25`, 26`, 27` y 29`
Sides 4 mm 4 mm
Top 25 mm 25 mm
Bottom 13 mm 25 mm
Note:
The following provides a space for easy installation,
proper air circulation and plumbing and electrical connections:
1. The space required for use in all products is: (As Table)
2. The doors are not reversible (applies to all models)
Capacity
Volume (I)
Storage
Areas
Total
storage
Gross
ft.
ft.
ft.
ft.
ft.
570
508
648
Note: The values can vary depending the model
