1–98 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
42668 A6B Phase TOC 2 Block 1 0 0x1DF 1 F89 0
42669 A6C Phase TOC 2 Block 2 0 0x1DF 1 F89 0
42670 A6D Phase TOC 2 Block 3 0 0x1DF 1 F89 0
42671 A6E Neutral TOC 2 Block 1 0 0x1DF 1 F89 0
42672 A6F Neutral TOC 2 Block 2 0 0x1DF 1 F89 0
42673 A70 Neutral TOC 2 Block 3 0 0x1DF 1 F89 0
42674 A71 Ground TOC 2 Block 1 0 0x1DF 1 F89 0
42675 A72 Ground TOC 2 Block 2 0 0x1DF 1 F89 0
42676 A73 Ground TOC 2 Block 3 0 0x1DF 1 F89 0
42677 A74 SGround TOC Block 1 0 0x1DF 1 F89 0
42678 A75 SGround TOC Block 2 0 0x1DF 1 F89 0
42679 A76 SGround TOC Block 3 0 0x1DF 1 F89 0
42719 A9E Thermal Model Block 1 0 0x1DF 1 F89 0
42720 A9F Thermal Model Block 2 0 0x1DF 1 F89 0
42721 AA0 Thermal Model Block 3 0 0x1DF 1 F89 0
42722 AA1 50SG IOC 1 Block 1 0 0x1DF 1 F89 0
42723 AA2 50SG IOC 1 Block 2 0 0x1DF 1 F89 0
42724 AA3 50SG IOC 1 Block 3 0 0x1DF 1 F89 0
42725 AA4 50SG IOC 2 Block 1 0 0x1DF 1 F89 0
42726 AA5 50SG IOC 2 Block 2 0 0x1DF 1 F89 0
42727 AA6 50SG IOC 2 Block 3 0 0x1DF 1 F89 0
42731 AAA Neg Seq TOC1 Block 1 0 0x1DF 1 F89 0
42732 AAB Neg Seq TOC1 Block 2 0 0x1DF 1 F89 0
42733 AAC Neg Seq TOC1 Block 3 0 0x1DF 1 F89 0
42734 AAD Neg Seq TOC2 Block 1 0 0x1DF 1 F89 0
42735 AAE Neg Seq TOC2 Block 2 0 0x1DF 1 F89 0
42736 AAF Neg Seq TOC2 Block 3 0 0x1DF 1 F89 0
PROTECTION ELEMENT RELAY CONFIGURATION
42737 AB0 50P IOC 1 Relays 0 0x7F 1 FC198 0
42738 AB1 50N IOC 1 Relays 0 0x7F 1 FC198 0
42739 AB2 50G IOC 1 Relays 0 0x7F 1 FC198 0
42740 AB3 51P TOC Relays 0 0x7F 1 FC198 0
42741 AB4 51N TOC Relays 0 0x7F 1 FC198 0
42742 AB5 51G TOC Relays 0 0x7F 1 FC198 0
42743 AB6 50P IOC 2 Relays 0 0x7F 1 FC198 0
42744 AB7 50N IOC 2 Relays 0 0x7F 1 FC198 0
42745 AB8 50G IOC 2 Relays 0 0x7F 1 FC198 0
42746 AB9 51P TOC 2 Relays 0 0x7F 1 FC198 0
42747 ABA 51N TOC 2 Relays 0 0x7F 1 FC198 0
42748 ABB 51G TOC 2 Relays 0 0x7F 1 FC198 0
42749 ABC 51SGTOCRelays 0 0x7F 1 FC198 0
42762 AC9 50SG IOC 1 Relays 0 0x7F 1 FC198 0
42763 ACA 50SG IOC 2 Relays 0 0x7F 1 FC198 0
42776 AD7 REF 1 Relays 0 0x7F 1 FC198 0
42777 AD8 REF 2 Relays 0 0x7F 1 FC198 0
42778 AD9 Inst Diff Relays 0 0x7F 1 FC198 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
