CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–97
42624 A3F Restd Gnd Fault 1 Func 0 3 1 FC197 0
42625 A40 CT Inputs 0 1 1 FC418 0
42626 A41 RGF 1 Pickup 2 2000 1 F3 5
42627 A42 RGF 1 Slope 0 100 1 F1 20
42628 A43 RGF 1 Delay 0 60000 1 F3 50
42629 A44 GND Current SPVSN 0 1 1 FC126 0
42630 A45 GND Current SPVSN Level 2 1000 1 F3 10
RESTRICTED GROUND FAULT2
42631 A46 Restd Gnd Fault 2 Func 0 3 1 FC197 0
42632 A47 CT Inputs 0 1 1 FC418 0
42633 A48 RGF 2 Pickup 2 2000 1 F3 5
42634 A49 RGF 2 Slope 0 100 1 F1 20
42635 A4A RGF 2 Delay 0 60000 1 F3 50
42636 A4B GND Current SPVSN 0 1 1 FC126 0
42637 A4C GND Current SPVSN Level 2 2000 1 F3 10
TRANSFORMER INSTANTANEOUS DIFFERENTIAL
42638 A4D Inst Diff Function 0 3 1 FC197 0
42639 A4E Inst Diff Pickup 300 2000 1 F3 800
PROTECTION FUNCTION BLOCKING
42641 A50 Phase IOC 1 Block 1 0 0x1DF 1 F89 0
42642 A51 Phase IOC 1 Block 2 0 0x1DF 1 F89 0
42643 A52 Phase IOC 1 Block 3 0 0x1DF 1 F89 0
42644 A53 Neutral IOC 1 Block 1 0 0x1DF 1 F89 0
42645 A54 Neutral IOC 1 Block 2 0 0x1DF 1 F89 0
42646 A55 Neutral IOC 1 Block 3 0 0x1DF 1 F89 0
42647 A56 Ground IOC 1 Block 1 0 0x1DF 1 F89 0
42648 A57 Ground IOC 1 Block 2 0 0x1DF 1 F89 0
42649 A58 Ground IOC 1 Block 3 0 0x1DF 1 F89 0
42650 A59 Phase TOC Block 1 0 0x1DF 1 F89 0
42651 A5A Phase TOC Block 2 0 0x1DF 1 F89 0
42652 A5B Phase TOC Block 3 0 0x1DF 1 F89 0
42653 A5C Neutral TOC Block 1 0 0x1DF 1 F89 0
42654 A5D Neutral TOC Block 2 0 0x1DF 1 F89 0
42655 A5E Neutral TOC Block 3 0 0x1DF 1 F89 0
42656 A5F Ground TOC Block 1 0 0x1DF 1 F89 0
42657 A60 Ground TOC Block 2 0 0x1DF 1 F89 0
42658 A61 Ground TOC Block 3 0 0x1DF 1 F89 0
42659 A62 Phase IOC 2 Block 1 0 0x1DF 1 F89 0
42660 A63 Phase IOC 2 Block 2 0 0x1DF 1 F89 0
42661 A64 Phase IOC 2 Block 3 0 0x1DF 1 F89 0
42662 A65 Neutral IOC 2 Block 1 0 0x1DF 1 F89 0
42663 A66 Neutral IOC 2 Block 2 0 0x1DF 1 F89 0
42664 A67 Neutral IOC 2 Block 3 0 0x1DF 1 F89 0
42665 A68 Ground IOC 2 Block 1 0 0x1DF 1 F89 0
42666 A69 Ground IOC 2 Block 2 0 0x1DF 1 F89 0
42667 A6A Ground IOC 2 Block 3 0 0x1DF 1 F89 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
