1–96 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
42530 9E1 Phase Time OC 2 Pickup 4 2000 1 F3 100
42531 9E2 Phase Time OC 2 Curve 0 14 1 F36 0
42532 9E3 Phase Time OC 2 Mult 5 2000 1 F3 100
42533 9E4 Phase Time OC 2 Reset 0 1 1 F68 0
NEUTRAL TOC2
42535 9E6 Neutral Time OC 2 Function 0 3 1 FC197 0
42536 9E7 Neutral Time OC 2 Pickup 4 2000 1 F3 100
42537 9E8 Neutral Time OC 2 Curve 0 14 1 F36 0
42538 9E9 Neutral Time OC 2 Mult 5 2000 1 F3 100
42539 9EA Neutral Time OC 2 Reset 0 1 1 F68 0
GROUND TOC2
42541 9EC GND Time OC 2 Function 0 3 1 FC197 0
42542 9ED GND Time OC 2 Pickup 4 2000 1 F3 100
42543 9EE GND Time OC 2 Curve 0 14 1 F36 0
42544 9EF GND Time OC 2 Mult 5 2000 1 F3 100
42545 9F0 GND Time OC 2 Reset 0 1 1 F68 0
SENSITIVE GROUND TOC1
42547 9F2 Sensitive Ground Time OC
Function
0 3 1 FC197 0
42548 9F3 Sensitive Ground Time OC Pickup 5 3000 1 F17A 1000
42549 9F4 Sensitive Ground Time OC Curve 0 14 1 F36 0
42550 9F5 Sensitive Ground Time OC Mult 5 2000 1 F3 100
42551 9F6 Sensitive Ground Time OC Reset 0 1 1 F68 0
SENSITIVE GROUND IOC1
42598 A25 Sensitive Ground Inst OC
Function
0 3 1 FC197 0
42599 A26 Sensitive Ground Inst OC Pickup 5 3000 1 F17A 1000
42600 A27 Sensitive Ground Inst OC Delay 0 30000 1 F3 0
SENSITIVE GROUND IOC2
42601 A28 Sensitive Ground2 Inst OC
Function
0 3 1 FC197 0
42602 A29 Sensitive Ground2 Inst OC Pickup 5 3000 1 F17A 1000
42603 A2A Sensitive Ground2 Inst OC Delay 0 30000 1 F3 0
TRANSFORMER PERCENT DIFFERENTIAL
42608 A2F XFMR Pcnt Func 0 3 1 FC197 0
42609 A30 Minimum Diff Pkp 5 100 1 F3 10
42610 A31 Slope1 15 100 1 F1 30
42611 A32 Break 1 50 400 1 F3 150
42612 A33 Break 2 100 1000 1 F3 150
42613 A34 Slope 2 50 100 1 F1 95
42614 A35 Inrush Inhbit Func 0 1 1 FC408 1
42615 A36 Inrush Level 1 400 1 F2 200
42616 A37 Inrush Inhibit Mode 0 2 1 FC409 0
42617 A38 Overexcitation Func 0 1 1 FC410 0
42618 A39 Overexcitation Level 10 400 1 F2 100
42619 A3A Output Relays 0 0x7F 1 FC198 0
RESTRICTED GROUND FAULT1
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
