CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–95
42266 8D9 Breaker Failure Relays 0 0x7F 1 FC198 0
42267 8DA BF EXT INITIATE 0 0x1DF 1 F89 0
PHASE IOC1
42485 9B4 Phase Inst OC Function 0 3 1 FC197 0
42486 9B5 Phase Inst OC Pickup 5 2000 1 F3 100
42487 9B6 Phase Inst OC Delay 0 30000 1 F3 0
NEUTRAL IOC1
42490 9B9 Neutral Inst OC Function 0 3 1 FC197 0
42491 9BA Neutral Inst OC Pickup 5 2000 1 F3 100
42492 9BB Neutral Inst OC Delay 0 30000 1 F3 0
GROUND IOC1
42494 9BD GND Inst OC Function 0 3 1 FC197 0
42495 9BE GND Inst OC Pickup 5 2000 1 F3 100
42496 9BF GND Inst OC Delay 0 30000 1 F3 0
PHASE TOC1
42498 9C1 Phase Time OC Function 0 3 1 FC197 0
42499 9C2 Phase Time OC Pickup 4 2000 1 F3 100
42500 9C3 Phase Time OC Curve 0 14 1 F36 0
42501 9C4 Phase Time OC Mult 5 2000 1 F3 100
42502 9C5 Phase Time OC Reset 0 1 1 F68 0
NEUTRAL TOC1
42504 9C7 Neutral Time OC Function 0 3 1 FC197 0
42505 9C8 Neutral Time OC Pickup 5 2000 1 F3 100
42506 9C9 Neutral Time OC Curve 0 14 1 F36 0
42507 9CA Neutral Time OC Mult 5 2000 1 F3 100
42508 9CB Neutral Time OC Reset 0 1 1 F68 0
GROUND TOC1
42510 9CD GND Time OC Function 0 3 1 FC197 0
42511 9CE GND Time OC Pickup 4 2000 1 F3 100
42512 9CF GND Time OC Curve 0 14 1 F36 0
42513 9D0 GND Time OC Mult 5 2000 1 F3 100
42514 9D1 GND Time OC Reset 0 1 1 F68 0
PHASE IOC2
42516 9D3 Phase Inst OC 2 Function 0 3 1 FC197 0
42517 9D4 Phase Inst OC 2 Pickup 5 2000 1 F3 100
42518 9D5 Phase Inst OC 2 Delay 0 30000 1 F3 0
NEUTRAL IOC2
42521 9D8 Neutral Inst OC 2 Function 0 3 1 FC197 0
42522 9D9 Neutral Inst OC 2 Pickup 5 2000 1 F3 100
42523 9DA Neutral Inst OC 2 Delay 0 30000 1 F3 0
GROUND IOC2
42525 9DC GND Inst OC 2 Function 0 3 1 FC197 0
42526 9DD GND Inst OC 2 Pickup 5 2000 1 F3 100
42527 9DE GNDl Inst OC 2 Delay 0 30000 1 F3 0
PHASE TOC2
42529 9E0 Phase Time OC 2 Function 0 3 1 FC197 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
