MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
CONTACT INPUT NAMES (9 - 10)
41435 59A Input Name 9 0 9 1 F22 165
41444 5A3 Input Name 10 0 9 1 F22 166
CONTACT INPUTS
41454 5AD Input 9 Debounce Interval 1 64 1 F1 2
41455 5AE Input 10 Debounce Interval 1 64 1 F1 2
41456 5AF Input 1 Debounce Interval 1 64 1 F1 2
41457 5B0 Input 2 Debounce Interval 1 64 1 F1 2
41458 5B1 Input 3 Debounce Interval 1 64 1 F1 2
41459 5B2 Input 4 Debounce Interval 1 64 1 F1 2
41460 5B3 Input 5 Debounce Interval 1 64 1 F1 2
41461 5B4 Input 6 Debounce Interval 1 64 1 F1 2
41462 5B5 Input 7 Debounce Interval 1 64 1 F1 2
41463 5B6 Input 8 Debounce Interval 1 64 1 F1 2
41465 5B8 Select DC Voltage 0 3 1 FC123 2
FRONT PANEL SETUP
41475 5C2 Screen Saver 0 10000 1 F1C 0
41498 5D9 Breaker Open LED color 0 3 1 FC157 2
41498 5D9 W1 Breaker Open color 0 3 1 FC157 2
41500 5DB W1 Breaker Closed color 0 3 1 FC157 2
41502 5DD W2 Breaker Open color 0 3 1 FC157 2
41504 5DF W2 Breaker Closed color 0 3 1 FC157 2
OUTPUT RELAYS
41510 5E5 Relay 3 Type 0 1 1 FC199 0
41511 5E6 Relay 4 Type 0 1 1 FC199 0
41512 5E7 Relay 5 Type 0 1 1 FC199 0
41513 5E8 Relay 6 Type 0 1 1 FC199 0
41547 60A BLOCK RLY 1 TRIP 0 0x1DF 1 F89 0
41549 60C BLOCK RLY 2 TRIP 0 0x1DF 1 F89 0
COIL MONITORS
42214 8A5 BYPASS BKR STATUS 0 1 1 FC126 0
42215 8A6 Relay1 Coil Monitor Function 0 2 1 FC206 0
42216 8A7 Relay1 Coil Monitor Pickup 1 10 1 F1 5
42217 8A8 Relay1 Coil Monitor Relay 0 0x7F 1 FC198 0
42218 8A9 BYPASS BKR STATUS 0 1 1 FC126 0
42219 8AA Relay2 Coil Monitor Function 0 2 1 FC206 0
42220 8AB Relay2 Coil Monitor Pickup 1 10 1 F1 5
42221 8AC Relay2 Coil Monitor Relay 0 0x7F 1 FC198 0
TRIP RELAY SEAL-IN
42222 8AD RLY 1 SEAL-IN 0 999 1 F3 4
42224 8AF RELAY 2 TRIP SEAL IN: 0 999 1 F3 4
W1 BREAKER FAIL
42262 8D5 Breaker Failure Function 0 2 1 FC206 0
42263 8D6 Breaker Failure Delay 1 3 100 1 F3 10
42264 8D7 Breaker Failure Current 5 2000 1 F3 100
42265 8D8 Breaker Failure Delay 2 0 100 1 F3 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
