GE 345

CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–117
44487 1186 103 Fourth ASDU Third Analogue
Entry
0 46 1 F88A 0
44488 1187 103 Fourth ASDU Third Analogue
Factor
00xFFFF1F30
44489 1188 103 Fourth ASDU Third Analogue
Offset
00xFFFF1F10
44490 1189 103 Fourth ASDU Fourth
Analogue Entry
0 46 1 F88A 0
44491 118A 103 Fourth ASDU Fourth
Analogue Factor
00xFFFF1F30
44492 118B 103 Fourth ASDU Fourth
Analogue Offset
00xFFFF1F10
44493 118C 103 Fourth ASDU Fifth Analogue
Entry
0 46 1 F88A 0
44494 118D 103 Fourth ASDU Fifth Analogue
Factor
00xFFFF1F30
44495 118E 103 Fourth ASDU Fifth Analogue
Offset
00xFFFF1F10
44496 118F 103 Fourth ASDU Sixth Analogue
Entry
0 46 1 F88A 0
44497 1190 103 Fourth ASDU Sixth Analogue
Factor
00xFFFF1F30
44498 1191 103 Fourth ASDU Sixth Analogue
Offset
00xFFFF1F10
44499 1192 103 Fourth ASDU Seventh
Analogue Entry
0 46 1 F88A 0
44500 1193 103 Fourth ASDU Seventh
Analogue Factor
00xFFFF1F30
44501 1194 103 Fourth ASDU Seventh
Analogue Offset
00xFFFF1F10
44502 1195 103 Fourth ASDU Eigth Analogue
Entry
0 46 1 F88A 0
44503 1196 103 Fourth ASDU Eigth Analogue
Factor
00xFFFF1F30
44504 1197 103 Fourth ASDU Eigth Analogue
Offset
00xFFFF1F10
44505 1198 103 Fourth ASDU Ninth Analogue
Entry
0 46 1 F88A 0
44506 1199 103 Fourth ASDU Ninth Analogue
Factor
00xFFFF1F30
44507 119A 103 Fourth ASDU Ninth Analogue
Offset
00xFFFF1F10
PASSWORD SECURITY
44536 11B7 Sec Passcode Master 1 0 1 1 F22 0
44537 11B8 Sec Passcode Master 2 0 1 1 F22 0
44538 11B9 Sec Passcode Master 3 0 1 1 F22 0
44539 11BA Sec Passcode Master 4 0 1 1 F22 0
44540 11BB Sec Passcode Master 5 0 1 1 F22 0
44541 11BC Sec Passcode Local SP 1 0 1 1 F22 0
44542 11BD Sec Passcode Local SP 2 0 1 1 F22 0
44543 11BE Sec Passcode Local SP 3 0 1 1 F22 0
44544 11BF Sec Passcode Local SP 4 0 1 1 F22 0
44545 11C0 Sec Passcode Local SP 5 0 1 1 F22 0
44546 11C1 Sec Passcode Local CRTL 1 0 1 1 F22 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
