GE 345

1–118 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
44547 11C2 Sec Passcode Local CRTL 2 0 1 1 F22 0
44548 11C3 Sec Passcode Local CRTL 3 0 1 1 F22 0
44549 11C4 Sec Passcode Local CRTL 4 0 1 1 F22 0
44550 11C5 Sec Passcode Local CRTL 5 0 1 1 F22 0
44551 11C6 Sec Passcode Remote SP 1 0 1 1 F22 0
44552 11C7 Sec Passcode Remote SP 2 0 1 1 F22 0
44553 11C8 Sec Passcode Remote SP 3 0 1 1 F22 0
44554 11C9 Sec Passcode Remote SP 4 0 1 1 F22 0
44555 11CA Sec Passcode Remote SP 5 0 1 1 F22 0
44556 11CB Sec Passcode Remote CTRL 1 0 1 1 F22 0
44557 11CC Sec Passcode Remote CTRL 2 0 1 1 F22 0
44558 11CD Sec Passcode Remote CTRL 3 0 1 1 F22 0
44559 11CE Sec Passcode Remote CTRL 4 0 1 1 F22 0
44560 11CF Sec Passcode Remote CTRL 5 0 1 1 F22 0
44561 11D0 Sec Passcode Entry Master 1 0 1 1 F22 0
44562 11D1 Sec Passcode Entry Master 2 0 1 1 F22 0
44563 11D2 Sec Passcode Entry Master 3 0 1 1 F22 0
44564 11D3 Sec Passcode Entry Master 4 0 1 1 F22 0
44565 11D4 Sec Passcode Entry Master 5 0 1 1 F22 0
44566 11D5 Sec Passcode Entry Setpoints 1 0 1 1 F22 0
44567 11D6 Sec Passcode Entry Setpoints 2 0 1 1 F22 0
44568 11D7 Sec Passcode Entry Setpoints 3 0 1 1 F22 0
44569 11D8 Sec Passcode Entry Setpoints 4 0 1 1 F22 0
44570 11D9 Sec Passcode Entry Setpoints 5 0 1 1 F22 0
44571 11DA Sec Passcode Entry Control 1 0 1 1 F22 0
44572 11DB Sec Passcode Entry Control 2 0 1 1 F22 0
44573 11DC Sec Passcode Entry Control 3 0 1 1 F22 0
44574 11DD Sec Passcode Entry Control 4 0 1 1 F22 0
44575 11DE Sec Passcode Entry Control 5 0 1 1 F22 0
44576 11DF O/W Local SP Pwd 0 1 1 FC103A 0
VIRTUAL INPUTS
44580 11E3 Virtual Input 1 Function 0 1 1 FC126 0
44581 11E4 Virtual Input 2 Function 0 1 1 FC126 0
44582 11E5 Virtual Input 3 Function 0 1 1 FC126 0
44583 11E6 Virtual Input 4 Function 0 1 1 FC126 0
44584 11E7 Virtual Input 5 Function 0 1 1 FC126 0
44585 11E8 Virtual Input 6 Function 0 1 1 FC126 0
44586 11E9 Virtual Input 7 Function 0 1 1 FC126 0
44587 11EA Virtual Input 8 Function 0 1 1 FC126 0
44588 11EB Virtual Input 9 Function 0 1 1 FC126 0
44589 11EC Virtual Input 10 Function 0 1 1 FC126 0
44590 11ED Virtual Input 11 Function 0 1 1 FC126 0
44591 11EE Virtual Input 12 Function 0 1 1 FC126 0
44592 11EF Virtual Input 13 Function 0 1 1 FC126 0
44593 11F0 Virtual Input 14 Function 0 1 1 FC126 0
44594 11F1 Virtual Input 15 Function 0 1 1 FC126 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
