CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–123
IEC61850 GOOSE REMOTE INPUTS
45567 15BE RI 1 NAME 0 7 1 F22 112
45583 15CE RI 1 GOOSE SOURCE 0 0x80 1 FC219 0
45584 15CF RI 1 ITEM SOURCE 0 0xFFFF 1 FC217 0
45585 15D0 RI 1 ITEM MASK 0 0xFFFF 1 FC218 0
45586 15D1 RI 1 DFLT STATE 0 3 1 FC220 1
45588 15D3 RI 2 NAME 0 7 1 F22 113
45604 15E3 RI 2 GOOSE SOURCE 0 0x80 1 FC219 0
45605 15E4 RI 2 ITEM SOURCE 0 0xFFFF 1 FC217 0
45606 15E5 RI 2 ITEM MASK 0 0xFFFF 1 FC218 0
45607 15E6 RI 2 DFLT STATE 0 3 1 FC220 1
45609 15E8 RI 3 NAME 0 7 1 F22 114
45625 15F8 RI 3 GOOSE SOURCE 0 0x80 1 FC219 0
45626 15F9 RI 3 ITEM SOURCE 0 0xFFFF 1 FC217 0
45627 15FA RI 3 ITEM MASK 0 0xFFFF 1 FC218 0
45628 15FB RI 3 DFLT STATE 0 3 1 FC220 1
45630 15FD RI 4 NAME 0 7 1 F22 115
45646 160D RI 4 GOOSE SOURCE 0 0x80 1 FC219 0
45647 160E RI 4 ITEM SOURCE 0 0xFFFF 1 FC217 0
45648 160F RI 4 ITEM MASK 0 0xFFFF 1 FC218 0
45649 1610 RI 4 DFLT STATE 0 3 1 FC220 1
45651 1612 RI 5 NAME 0 7 1 F22 116
45667 1622 RI 5 GOOSE SOURCE 0 0x80 1 FC219 0
45668 1623 RI 5 ITEM SOURCE 0 0xFFFF 1 FC217 0
45669 1624 RI 5 ITEM MASK 0 0xFFFF 1 FC218 0
45670 1625 RI 5 DFLT STATE 0 3 1 FC220 1
45672 1627 RI 6 NAME 0 7 1 F22 117
45688 1637 RI 6 GOOSE SOURCE 0 0x80 1 FC219 0
45689 1638 RI 6 ITEM SOURCE 0 0xFFFF 1 FC217 0
45690 1639 RI 6 ITEM MASK 0 0xFFFF 1 FC218 0
45691 163A RI 6 DFLT STATE 0 3 1 FC220 1
45693 163C RI 7 NAME 0 7 1 F22 118
45709 164C RI 7 GOOSE SOURCE 0 0x80 1 FC219 0
45710 164D RI 7 ITEM SOURCE 0 0xFFFF 1 FC217 0
45711 164E RI 7 ITEM MASK 0 0xFFFF 1 FC218 0
45712 164F RI 7 DFLT STATE 0 3 1 FC220 1
45714 1651 RI 8 NAME 0 7 1 F22 119
45730 1661 RI 8 GOOSE SOURCE 0 0x80 1 FC219 0
45731 1662 RI 8 ITEM SOURCE 0 0xFFFF 1 FC217 0
45732 1663 RI 8 ITEM MASK 0 0xFFFF 1 FC218 0
45733 1664 RI 8 DFLT STATE 0 3 1 FC220 1
45735 1666 RI 9 NAME 0 7 1 F22 120
45751 1676 RI 9 GOOSE SOURCE 0 0x80 1 F1 0
45752 1677 RI 9 ITEM SOURCE 0 0xFFFF 1 FC217 0
45753 1678 RI 9 ITEM MASK 0 0xFFFF 1 FC218 0
45754 1679 RI 9 DFLT STATE 0 3 1 FC220 1
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
