1–124 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
45756 167B RI 10 NAME 0 7 1 F22 121
45772 168B RI 10 GOOSE SOURCE 0 0x80 1 F1 0
45773 168C RI 10 ITEM SOURCE 0 0xFFFF 1 FC217 0
45774 168D RI 10 ITEM MASK 0 0xFFFF 1 FC218 0
45775 168E RI 10 DFLT STATE 0 3 1 FC220 1
45777 1690 RI 11 NAME 0 7 1 F22 122
45793 16A0 RI 11 GOOSE SOURCE 0 0x80 1 F1 0
45794 16A1 RI 11 ITEM SOURCE 0 0xFFFF 1 FC217 0
45795 16A2 RI 11 ITEM MASK 0 0xFFFF 1 FC218 0
45796 16A3 RI 11 DFLT STATE 0 3 1 FC220 1
45798 16A5 RI 12 NAME 0 7 1 F22 123
45814 16B5 RI 12 GOOSE SOURCE 0 0x80 1 F1 0
45815 16B6 RI 12 ITEM SOURCE 0 0xFFFF 1 FC217 0
45816 16B7 RI 12 ITEM MASK 0 0xFFFF 1 FC218 0
45817 16B8 RI 12 DFLT STATE 0 3 1 FC220 1
45819 16BA RI 13 NAME 0 7 1 F22 124
45835 16CA RI 13 GOOSE SOURCE 0 0x80 1 F1 0
45836 16CB RI 13 ITEM SOURCE 0 0xFFFF 1 FC217 0
45837 16CC RI 13 ITEM MASK 0 0xFFFF 1 FC218 0
45838 16CD RI 13 DFLT STATE 0 3 1 FC220 1
45840 16CF RI 14 NAME 0 7 1 F22 125
45856 16DF RI 14 GOOSE SOURCE 0 0x80 1 F1 0
45857 16E0 RI 14 ITEM SOURCE 0 0xFFFF 1 FC217 0
45858 16E1 RI 14 ITEM MASK 0 0xFFFF 1 FC218 0
45859 16E2 RI 14 DFLT STATE 0 3 1 FC220 1
45861 16E4 RI 15 NAME 0 7 1 F22 126
45877 16F4 RI 15 GOOSE SOURCE 0 0x80 1 F1 0
45878 16F5 RI 15 ITEM SOURCE 0 0xFFFF 1 FC217 0
45879 16F6 RI 15 ITEM MASK 0 0xFFFF 1 FC218 0
45880 16F7 RI 15 DFLT STATE 0 3 1 FC220 1
45882 16F9 RI 16 NAME 0 7 1 F22 127
45898 1709 RI 16 GOOSE SOURCE 0 0x80 1 F1 0
45899 170A RI 16 ITEM SOURCE 0 0xFFFF 1 FC217 0
45900 170B RI 16 ITEM MASK 0 0xFFFF 1 FC218 0
45901 170C RI 16 DFLT STATE 0 3 1 FC220 1
45903 170E RI 17 NAME 0 7 1 F22 128
45919 171E RI 17 GOOSE SOURCE 0 0x80 1 F1 0
45920 171F RI 17 ITEM SOURCE 0 0xFFFF 1 FC217 0
45921 1720 RI 17 ITEM MASK 0 0xFFFF 1 FC218 0
45922 1721 RI 17 DFLT STATE 0 3 1 FC220 1
45924 1723 RI 18 NAME 0 7 1 F22 129
45940 1733 RI 18 GOOSE SOURCE 0 0x80 1 F1 0
45941 1734 RI 18 ITEM SOURCE 0 0xFFFF 1 FC217 0
45942 1735 RI 18 ITEM MASK 0 0xFFFF 1 FC218 0
45943 1736 RI 18 DFLT STATE 0 3 1 FC220 1
45945 1738 RI 19 NAME 0 7 1 F22 130
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
