GE 345

CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–131
F80 unsigned 16 bits DNP Object 22 Default Variation
1Variation One
2Variation Two
5Variation Five
6 Variation Six
F81 unsigned 16 bits DNP Object 23 Default Variation
1Variation One
2Variation Two
5Variation Five
6 Variation Six
F82 unsigned 16 bits DNP Object 30 Default Variation
1Variation One
2Variation Two
3Variation Three
4Variation Four
F83 unsigned 16 bits DNP Object 32 Default Variation
1Variation One
2Variation Two
3Variation Three
4Variation Four
F85 unsigned 16 bits DNP Analog Input Point Scale Factor
1 / 0.001
2 / 0.01
3 / 0.1
4/ 1
5 / 10
6 / 100
7 / 1000
8 / 10000
9 / 100000
F86 unsigned 16 bits DNP and 103 Binary Output Points
0Off
1Virtual Input 1
2Virtual Input 2
3Virtual Input 3
4Virtual Input 4
5Virtual Input 5
6Virtual Input 6
7Virtual Input 7
8Virtual Input 8
9Virtual Input 9
10 Virtual Input 10
11 Virtual Input 11
12 Virtual Input 12
13 Virtual Input 13
14 Virtual Input 14
15 Virtual Input 15
Code Type Definition
