1–132 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
16 Virtual Input 16
17 Virtual Input 17
18 Virtual Input 18
19 Virtual Input 19
20 Virtual Input 20
21 Virtual Input 21
22 Virtual Input 22
23 Virtual Input 23
24 Virtual Input 24
25 Virtual Input 25
26 Virtual Input 26
27 Virtual Input 27
28 Virtual Input 28
29 Virtual Input 29
30 Virtual Input 30
31 Virtual Input 31
32 Virtual Input 32
33 Force Coil: Reset
36 Force Coil: Display Msg
F87 unsigned 16 bits DNP/Ethernet Channel Port
0None
1TCP
2UDP
F88A unsigned 16 bits Analog Values
0 Disabled
1 Phase A Current
2Phase B Current
3Phase C Current
7 Ground Current
23 Therm Cap. Phase A
24 Therm Cap. Phase B
25 Therm Cap. Phase C
26 Neutral Current
29 Neg. Seq Current
30 Phase A Current W2
31 Phase B Current W2
32 Phase C Current W2
43 SGnd Current
33 Ground Current W2
44 Neg. Seq Current W2
34 W2 SGnd Current
45 Neutral Current W2
35 Ph A Diff Current
36 Ph B Diff Current
37 Ph C Diff Current
38 Ph A RESTR Current
39 Ph B RESTR Current
Code Type Definition
