GE 345

1–142 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0x9081 Gnd IOC1 Trip PKP
0x9082 Gnd IOC1 Trip Op
0x9084 Gnd IOC1 Trip DPO
0x90C1 Ph TOC Trip PKP
0x90C2 Ph TOC Trip Op
0x90C4 Ph TOC Trip DPO
0x90C9 Ph A TOC Trip PKP
0x90CA Ph A TOC Trip Op
0x90CC Ph A TOC Trip DPO
0x90D1 Ph B TOC Trip PKP
0x90D2 Ph B TOC Trip Op
0x90D4 Ph B TOC Trip DPO
0x90E1 Ph C TOC Trip PKP
0x90E2 Ph C TOC Trip Op
0x90E4 Ph C TOC Trip DPO
0x9101 Ntrl TOC Trip PKP
0x9102 Ntrl TOC Trip Op
0x9104 Ntrl TOC Trip DPO
0x9141 Gnd TOC Trip PKP
0x9142 Gnd TOC Trip Op
0x9144 Gnd TOC Trip DPO
0x9181 Ph IOC2 Trip PKP
0x9182 Ph IOC2 Trip Op
0x9184 Ph IOC2 Trip DPO
0x9189 Ph A IOC2 Trip PKP
0x918A Ph A IOC2 Trip Op
0x918C Ph A IOC2 Trip DPO
0x9191 Ph B IOC2 Trip PKP
0x9192 Ph B IOC2 Trip Op
0x9194 Ph B IOC2 Trip DPO
0x91A1 Ph C IOC2 Trip PKP
0x91A2 Ph C IOC2 Trip Op
0x91A4 Ph C IOC2 Trip DPO
0x91C1 Ntrl IOC2 Trip PKP
0x91C2 Ntrl IOC2 Trip Op
0x91C4 Ntrl IOC2 Trip DPO
0x9201 Gnd IOC2 Trip PKP
0x9202 Gnd IOC2 Trip Op
0x9204 Gnd IOC2 Trip DPO
0x9241 Ph TOC2 Trip PKP
0x9242 Ph TOC2 Trip Op
0x9244 Ph TOC2 Trip DPO
0x9249 Ph A TOC2 Trip PKP
0x924A Ph A TOC2 Trip Op
0x924C Ph A TOC2 Trip DPO
0x9251 Ph B TOC2 Trip PKP
0x9252 Ph B TOC2 Trip Op
Code Type Definition
