CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–143
0x9254 Ph B TOC2 Trip DPO
0x9261 Ph C TOC2 Trip PKP
0x9262 Ph C TOC2 Trip Op
0x9264 Ph C TOC2 Trip DPO
0x9281 Ntrl TOC2 Trip PKP
0x9282 Ntrl TOC2 Trip Op
0x9284 Ntrl TOC2 Trip DPO
0x92C1 Gnd TOC2 Trip PKP
0x92C2 Gnd TOC2 Trip Op
0x92C4 Gnd TOC2 Trip DPO
0x9301 SGnd TOC Trp PKP
0x9302 SGnd TOC Trp Op
0x9304 SGnd TOC Trp DPO
0x9641 SGnd IOC1 Trip PKP
0x9642 SGnd IOC1 Trip Op
0x9644 SGnd IOC1 Trip DPO
0x9681 SGnd IOC2 Trip PKP
0x9682 SGnd IOC2 Trip Op
0x9684 SGnd IOC2 Trip DPO
0x9701 Pcnt Diff Trip PKP
0x9702 Pcnt Diff Trip Op
0x9704 Pcnt Diff Trip DPO
0x9709 Ph A Diff Trip PKP
0x970A Ph A Diff Trip Op
0x970C Ph A Diff Trip DPO
0x9711 Ph B Diff Trip PKP
0x9712 Ph B Diff Trip Op
0x9714 Ph B Diff Trip DPO
0x9721 Ph C Diff Trip PKP
0x9722 Ph C Diff Trip Op
0x9724 Ph C Diff Trip DPO
0x9741 RGF1 Trip PKP
0x9742 RGF1 Diff Trip Op
0x9744 RGF1 Diff Trip DPO
0x9781 RGF2 Diff Trip PKP
0x9782 RGF2 Diff Trip Op
0x9784 RGF2 Diff Trip DPO
0x97C1 Inst Diff Trip PKP
0x97C2 Inst Diff Trip Op
0x97C4 Inst Diff Trip DPO
0x9801 NSeq TOC1 Trip PKP
0x9802 NSeq TOC1 Trip Op
0x9804 NSeq TOC1 Trip DPO
0x9841 NSeq TOC2 Trip PKP
0x9842 NSeq TOC2 Trip Op
0x9844 NSeq TOC2 Trip DPO
0x99C1 SGnd TOC2 Trip PKP
Code Type Definition
