1–144 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0x99C2 SGnd TOC2 Trip Op
0x99C4 SGnd TOC2 Trip DPO
0xA049 Therm PhA Alrm PKP
0xA04A Therm PhA Alrm Op
0xA04C Therm PhA Alrm DPO
0xA051 Therm PhB Alrm PKP
0xA052 Therm PhB Alrm Op
0xA054 Therm PhB Alrm DPO
0xA061 Therm PhC Alrm PKP
0xA062 Therm PhC Alrm Op
0xA064 Therm PhC Alrm DPO
0xA482 Relay Not Ready
0xA4C1 LE 1 Alarm PKP
0xA4C2 LE 1 Alarm Op
0xA4C4 LE 1 Alarm DPO
0xA501 LE 2 Alarm PKP
0xA502 LE 2 Alarm Op
0xA504 LE 2 Alarm DPO
0xA541 LE 3 Alarm PKP
0xA542 LE 3 Alarm Op
0xA544 LE 3 Alarm DPO
0xA581 LE 4 Alarm PKP
0xA582 LE 4 Alarm Op
0xA584 LE 4 Alarm DPO
0xA5C1 LE 5 Alarm PKP
0xA5C2 LE 5 Alarm Op
0xA5C4 LE 5 Alarm DPO
0xA601 LE 6 Alarm PKP
0xA602 LE 6 Alarm Op
0xA604 LE 6 Alarm DPO
0xA641 LE 7 Alarm PKP
0xA642 LE 7 Alarm Op
0xA644 LE 7 Alarm DPO
0xA681 LE 8 Alarm PKP
0xA682 LE 8 Alarm Op
0xA684 LE 8 Alarm DPO
0xAC42 Self-Test Alarm OP
0xAD02 TrpCoilMonAlrm Op
0xAD42 ClsCoilMonAlrm Op
0xAD81 BKR1 Fail Alrm PKP
0xAD82 BKR1 Fail Alarm Op
0xAD84 BKR1 Fail Alarm DPO
0xADC2 BKR1 Stat Fail OP
0xAEC1 BKR2 Stat Fail PKP
0xAEC2 BKR2 Stat Fail Op
0xAF41 BKR2 Fail Alarm PKP
0xAF42 BKR2 Fail Alarm OP
Code Type Definition
