1–154 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0x01E8 Remote IN 9 Off
0x01E9 Remote IN 10 Off
0x01EA Remote IN 11 Off
0x01EB Remote IN 12 Off
0x01EC Remote IN 13 Off
0x01ED Remote IN 14 Off
0x01EE Remote IN 15 Off
0x01EF Remote IN 16 Off
0x01F0 Remote IN 17 Off
0x01F1 Remote IN 18 Off
0x01F2 Remote IN 19 Off
0x01F3 Remote IN 20 Off
0x01F4 Remote IN 21 Off
0x01F5 Remote IN 22 Off
0x01F6 Remote IN 23 Off
0x01F7 Remote IN 24 Off
0x01F8 Remote IN 25 Off
0x01F9 Remote IN 26 Off
0x01FA Remote IN 27 Off
0x01FB Remote IN 28 Off
0x01FC Remote IN 29 Off
0x01FD Remote IN 30 Off
0x01FE Remote IN 31 Off
0x01FF Remote IN 32 Off
0x8002 Any Trip
0x8042 Therm O/L Trip Op
0x8044 Therm O/L Trip DPO
0x804A Therm PhA Trip Op
0x804C Therm PhA Trip DPO
0x8052 Therm PhB Trip Op
0x8054 Therm PhB Trip DPO
0x8062 Therm PhC Trip Op
0x8064 Therm PhC Trip DPO
0x84C1 LE 1 Trip PKP
0x84C2 LE 1 Trip Op
0x84C4 LE 1 Trip DPO
0x8501 LE 2 Trip PKP
0x8502 LE 2 Trip Op
0x8504 LE 2 Trip DPO
0x8541 LE 3 Trip PKP
0x8542 LE 3 Trip Op
0x8544 LE 3 Trip DPO
0x8581 LE 4 Trip PKP
0x8582 LE 4 Trip Op
0x8584 LE 4 Trip DPO
0x85C1 LE 5 Trip PKP
0x85C2 LE 5 Trip Op
Code Type Definition
