CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–155
0x85C4 LE 5 Trip DPO
0x8601 LE 6 Trip PKP
0x8602 LE 6 Trip Op
0x8604 LE 6 Trip DPO
0x8641 LE 7 Trip PKP
0x8642 LE 7 Trip Op
0x8644 LE 7 Trip DPO
0x8681 LE 8 Trip PKP
0x8682 LE 8 Trip Op
0x8684 LE 8 Trip DPO
0x8CC2 BKRTrpCntr Op
0x8D01 TrpCoilMon Trp PKP
0x8D02 TrpCoilMon Trp Op
0x8D04 TrpCoilMon Trp DPO
0x8D41 ClsCoilMon Trp PKP
0x8D42 ClsCoilMon Trp Op
0x8D44 ClsCoilMon Trp DPO
0x8D81 BKR Failure PKP
0x8D82 BKR Failure Op
0x8D84 BKR Failure DPO
0x9001 Ph IOC1 Trip PKP
0x9002 Ph IOC1 Trip Op
0x9004 Ph IOC1 Trip DPO
0x9009 Ph A IOC1 Trip PKP
0x900A Ph A IOC1 Trip Op
0x900C Ph A IOC1 Trip DPO
0x9011 Ph B IOC1 Trip PKP
0x9012 Ph B IOC1 Trip Op
0x9014 Ph B IOC1 Trip DPO
0x9021 Ph C IOC1 Trip PKP
0x9022 Ph C IOC1 Trip Op
0x9024 Ph C IOC1 Trip DPO
0x9041 Ntrl IOC1 Trip PKP
0x9042 Ntrl IOC1 Trip Op
0x9044 Ntrl IOC1 Trip DPO
0x9081 Gnd IOC1 Trip PKP
0x9082 Gnd IOC1 Trip Op
0x9084 Gnd IOC1 Trip DPO
0x90C1 Ph TOC Trip PKP
0x90C2 Ph TOC Trip Op
0x90C4 Ph TOC Trip DPO
0x90C9 Ph A TOC Trip PKP
0x90CA Ph A TOC Trip Op
0x90CC Ph A TOC Trip DPO
0x90D1 Ph B TOC Trip PKP
0x90D2 Ph B TOC Trip Op
0x90D4 Ph B TOC Trip DPO
Code Type Definition
