1–156 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0x90E1 Ph C TOC Trip PKP
0x90E2 Ph C TOC Trip Op
0x90E4 Ph C TOC Trip DPO
0x9101 Ntrl TOC Trip PKP
0x9102 Ntrl TOC Trip Op
0x9104 Ntrl TOC Trip DPO
0x9141 Gnd TOC Trip PKP
0x9142 Gnd TOC Trip Op
0x9144 Gnd TOC Trip DPO
0x9181 Ph IOC2 Trip PKP
0x9182 Ph IOC2 Trip Op
0x9184 Ph IOC2 Trip DPO
0x9189 Ph A IOC2 Trip PKP
0x918A Ph A IOC2 Trip Op
0x918C Ph A IOC2 Trip DPO
0x9191 Ph B IOC2 Trip PKP
0x9192 Ph B IOC2 Trip Op
0x9194 Ph B IOC2 Trip DPO
0x91A1 Ph C IOC2 Trip PKP
0x91A2 Ph C IOC2 Trip Op
0x91A4 Ph C IOC2 Trip DPO
0x91C1 Ntrl IOC2 Trip PKP
0x91C2 Ntrl IOC2 Trip Op
0x91C4 Ntrl IOC2 Trip DPO
0x9201 Gnd IOC2 Trip PKP
0x9202 Gnd IOC2 Trip Op
0x9204 Gnd IOC2 Trip DPO
0x9301 SGnd TOC Trp PKP
0x9302 SGnd TOC Trp Op
0x9304 SGnd TOC Trp DPO
0x9641 SGnd IOC1 Trip PKP
0x9642 SGnd IOC1 Trip Op
0x9644 SGnd IOC1 Trip DPO
0x9681 SGnd IOC2 Trip PKP
0x9682 SGnd IOC2 Trip Op
0x9684 SGnd IOC2 Trip DPO
0x9701 Pcnt Diff Trip PKP
0x9702 Pcnt Diff Trip Op
0x9704 Pcnt Diff Trip DPO
0x970A Ph Diff A Trip Op
0x970C Ph Diff A Trip DPO
0x9712 Ph Diff B Trip Op
0x9714 Ph Diff B Trip DPO
0x9722 Ph Diff C Trip Op
0x9724 Ph Diff C Trip DPO
0x9741 RGF1 Trip PKP
0x9742 RGF1 Trip Op
Code Type Definition
