GE 345

CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–157
0x9744 RGF1 Trip DPO
0x9781 RGF2 Trip PKP
0x9782 RGF2 Trip Op
0x9784 RGF2 Trip DPO
0x97C1 Inst Diff Trip PKP
0x97C2 Inst Diff Trip Op
0x97C4 Inst Diff Trip DPO
0x9801 NSeq TOC1 Trip PKP
0x9802 NSeq TOC1 Trip Op
0x9804 NSeq TOC1 Trip DPO
0x9841 NSeq TOC2 Trip PKP
0x9842 NSeq TOC2 Trip Op
0x9844 NSeq TOC2 Trip DPO
0x99C1 SGnd TOC2 Trip PKP
0x99C2 SGnd TOC2 Trip Op
0x99C4 SGnd TOC2 Trip DPO
0xA002 Any Alarm
0xA042 Therm Lvl Alrm Op
0xA044 Therm Lvl Alrm DPO
0xA04A Therm PhA Alrm Op
0xA04C Therm PhA Alrm DPO
0xA052 Therm PhB Alrm Op
0xA054 Therm PhB Alrm DPO
0xA062 Therm PhC Alrm Op
0xA064 Therm PhC Alrm DPO
0xA482 Relay Not Ready
0xA4C1 LE 1 Alarm PKP
0xA4C2 LE 1 Alarm Op
0xA4C4 LE 1 Alarm DPO
0xA501 LE 2 Alarm PKP
0xA502 LE 2 Alarm Op
0xA504 LE 2 Alarm DPO
0xA541 LE 3 Alarm PKP
0xA542 LE 3 Alarm Op
0xA544 LE 3 Alarm DPO
0xA581 LE 4 Alarm PKP
0xA582 LE 4 Alarm Op
0xA584 LE 4 Alarm DPO
0xA5C1 LE 5 Alarm PKP
0xA5C2 LE 5 Alarm Op
0xA5C4 LE 5 Alarm DPO
0xA601 LE 6 Alarm PKP
0xA602 LE 6 Alarm Op
0xA604 LE 6 Alarm DPO
0xA641 LE 7 Alarm PKP
0xA642 LE 7 Alarm Op
0xA644 LE 7 Alarm DPO
Code Type Definition
