1–158 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0xA681 LE 8 Alarm PKP
0xA682 LE 8 Alarm Op
0xA684 LE 8 Alarm DPO
0xAC42 Self-Test Alarm Op
0xACC1 BKRTrpCntrAlrm PKP
0xACC2 BKRTrpCntrAlrm Op
0xACC4 BKRTrpCntrAlrm DPO
0xAD01 TrpCoilMonAlrm PKP
0xAD02 TrpCoilMonAlrm Op
0xAD04 TrpCoilMonAlrm DPO
0xAD41 ClsCoilMonAlrm PKP
0xAD42 ClsCoilMonAlrm Op
0xAD44 ClsCoilMonAlrm DPO
0xAD81 BKR1 Fail Alrm PKP
0xAD82 BKR1 Fail Alarm Op
0xAD84 BKR1 Fail Alarm DPO
0xADC2 BKRStatus Fail
0xAEC2 BKR2 Stat Fail Op
0xAF41 BKR2 Fail Alrm PKP
0xAF42 BKR2 Fail Alrm Op
0xAF44 BKR2 Fail Alrm DPO
0xB001 Ph IOC1 Alarm PKP
0xB002 Ph IOC1 Alarm Op
0xB004 Ph IOC1 Alarm DPO
0xB009 Ph A IOC1 Alrm PKP
0xB00A Ph A IOC1 Alrm Op
0xB00C Ph A IOC1 Alrm DPO
0xB011 Ph B IOC1 Alrm PKP
0xB012 Ph B IOC1 Alrm Op
0xB014 Ph B IOC1 Alrm DPO
0xB021 Ph C IOC1 Alrm PKP
0xB022 Ph C IOC1 Alrm Op
0xB024 Ph C IOC1 Alrm DPO
0xB041 Ntrl IOC1 Alrm PKP
0xB042 Ntrl IOC1 Alrm Op
0xB044 Ntrl IOC1 Alrm DPO
0xB081 Gnd IOC1 Alarm PKP
0xB082 Gnd IOC1 Alarm Op
0xB084 Gnd IOC1 Alarm DPO
0xB0C1 Ph TOC Alarm PKP
0xB0C2 Ph TOC Alarm Op
0xB0C4 Ph TOC Alarm DPO
0xB0C9 Ph A TOC Alrm PKP
0xB0CA Ph A TOC Alrm Op
0xB0CC Ph A TOC Alrm DPO
0xB0D1 Ph B TOC Alrm PKP
0xB0D2 Ph B TOC Alrm Op
Code Type Definition
