GE 345

1–160 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0xB302 SGnd TOC1 Alrm Op
0xB304 SGnd TOC1 Alrm DPO
0xB641 SGnd IOC1 Alrm PKP
0xB642 SGnd IOC1 Alrm Op
0xB644 SGnd IOC1 Alrm DPO
0xB681 SGnd IOC2 Alrm PKP
0xB682 SGnd IOC2 Alrm Op
0xB684 SGnd IOC2 Alrm DPO
0xB701 Pcnt Diff Alrm PKP
0xB702 Pcnt Diff IOC2 Alrm Op
0xB704 Pcnt Diff IOC2 Alrm DPO
0xB709 Ph Dif A Alarm PKP
0xB70A Ph Dif A Alarm Op
0xB70C Ph Dif A Alarm DPO
0xB711 Ph Dif B Alarm PKP
0xB712 Ph Dif B Alarm Op
0xB714 Ph Dif B Alarm DPO
0xB721 Ph Dif C Alarm PKP
0xB722 Ph Dif C Alarm Op
0xB724 Ph Dif C Alarm DPO
0xB741 RGF1 Alarm PKP
0xB742 RGF1 Alarm Op
0xB744 RGF1 Alarm DPO
0xB781 RGF2 Alarm PKP
0xB782 RGF2 Alarm Op
0xB784 RGF2 Alarm DPO
0xB7C1 Inst Diff Alrm PKP
0xB7C2 Inst Diff Alrm Op
0xB7C4 Inst Diff Alrm DPO
0xB801 NSeq TOC1 Alrm PKP
0xB802 NSeq TOC1 Alrm Op
0xB804 NSeq TOC1 Alrm DPO
0xB841 NSeq TOC2 Alrm PKP
0xB842 NSeq TOC2 Alrm Op
0xB844 NSeq TOC2 Alrm DPO
0xB9C1 SGnd TOC2 Alrm PKP
0xB9C2 SGnd TOC2 Alrm Op
0xB9C4 SGnd TOC2 Alrm DPO
0xC042 Output Relay 3 On
0xC082 Output Relay 4 On
0xC0C2 Output Relay 5 On
0xC102 Output Relay 6 On
0xC142 Self-Test Rly 7 On
0xC182 Rly #1 Trip OP
0xC1C2 Rly #2 Close OP
0xC202 BKR Connected
0xC2C2 BKR2 Connected
Code Type Definition
