GE 345

CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–161
0xC4C1 LE 1 PKP
0xC4C2 LE 1 Op
0xC4C4 LE 1 DPO
0xC501 LE 2 PKP
0xC502 LE 2 Op
0xC504 LE 2 DPO
0xC541 LE 3 PKP
0xC542 LE 3 Op
0xC544 LE 3 DPO
0xC581 LE 4 PKP
0xC582 LE 4 Op
0xC584 LE 4 DPO
0xC5C1 LE 5 PKP
0xC5C2 LE 5 Op
0xC5C4 LE 5 DPO
0xC601 LE 6 PKP
0xC602 LE 6 Op
0xC604 LE 6 DPO
0xC641 LE 7 PKP
0xC642 LE 7 Op
0xC644 LE 7 DPO
0xC681 LE 8 PKP
0xC682 LE 8 Op
0xC684 LE 8 DPO
0xC882 Setpoint Group 2
0xC982 Maint. Req. Op
0xCA02 52a Contact
0xCA42 52b Contact
0xCCC2 BKR Stat Open
0xCD02 BKR Stat Clsd
0xCD42 Setpoint Group 1
0xDA02 BKR2 52a Cont OP
0xDA42 BKR2 52b Cont OP
0xDA82 BKR2 Stat Open OP
0xDAC2 BKR2 Stat Clsd
0xDB02 Trip BKR1 OP
0xDB04 Trip BKR1 DPO
0xDB41 Trip BKR2 PKP
0xDB42 Trip BKR2 OP
0xDB44 Trip BKR2 DPO
0xDB8A 2nd Hmnc Diff Ph A
0xDB92 2nd Hmnc Diff Ph B
0xDBA2 2nd Hmnc Diff Ph C
0xDBCA 5th Hmnc Diff Ph A
0xDBD2 5th Hmnc Diff Ph B
0xDBE2 5th Hmnc Diff Ph C
0xE002 Any Block
Code Type Definition
