CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–91
40619 26A User Map Address 96 30001 39999 1 F1 30001
40620 26B User Map Address 97 30001 39999 1 F1 30001
40621 26C User Map Address 98 30001 39999 1 F1 30001
40622 26D User Map Address 99 30001 39999 1 F1 30001
40623 26E User Map Address 100 30001 39999 1 F1 30001
40624 26F User Map Address 101 30001 39999 1 F1 30001
40625 270 User Map Address 102 30001 39999 1 F1 30001
40626 271 User Map Address 103 30001 39999 1 F1 30001
40627 272 User Map Address 104 30001 39999 1 F1 30001
40628 273 User Map Address 105 30001 39999 1 F1 30001
40629 274 User Map Address 106 30001 39999 1 F1 30001
40630 275 User Map Address 107 30001 39999 1 F1 30001
40631 276 User Map Address 108 30001 39999 1 F1 30001
40632 277 User Map Address 109 30001 39999 1 F1 30001
40633 278 User Map Address 110 30001 39999 1 F1 30001
40634 279 User Map Address 111 30001 39999 1 F1 30001
40635 27A User Map Address 112 30001 39999 1 F1 30001
40636 27B User Map Address 113 30001 39999 1 F1 30001
40637 27C User Map Address 114 30001 39999 1 F1 30001
40638 27D User Map Address 115 30001 39999 1 F1 30001
40639 27E User Map Address 116 30001 39999 1 F1 30001
40640 27F User Map Address 117 30001 39999 1 F1 30001
40641 280 User Map Address 118 30001 39999 1 F1 30001
40642 281 User Map Address 119 30001 39999 1 F1 30001
40643 282 User Map Address 120 30001 39999 1 F1 30001
40644 283 User Map Address 121 30001 39999 1 F1 30001
40645 284 User Map Address 122 30001 39999 1 F1 30001
40646 285 User Map Address 123 30001 39999 1 F1 30001
40647 286 User Map Address 124 30001 39999 1 F1 30001
40648 287 User Map Address 125 30001 39999 1 F1 30001
TRANSIENT RECORDER TRIGGERS
40650 289 Trigger On Input 1 0 0x1DF 1 F89 0
40651 28A Trigger On Input 2 0 0x1DF 1 F89 0
40652 28B Trigger On Input 3 0 0x1DF 1 F89 0
EVENT RECORDER
40654 28D Recording of Pickup Events 0 1 1 FC126 1
40655 28E Recording of Contact Input
Events
0 1 1 FC126 1
40656 28F Recording of Virtual Input Events 0 1 1 FC126 1
40657 290 Recording of Remote Inputs 0 1 1 FC126 1
40658 291 Recording of Logic Element
Events
0 1 1 FC126 1
40660 293 Recording of Trip Events 0 1 1 FC126 1
40661 294 Recording of Alarm Events 0 1 1 FC126 1
40662 295 Recording of Control Events 0 1 1 FC126 1
40665 298 Recording of Dropout Events 0 1 1 FC126 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
