1–92 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
40666 299 Recording of Set Time/Date
Events
0 1 1 FC126 0
40667 29A Event Record Selector 1 65535 1 F1 1
TRANSIENT RECORDER
40668 29B Trigger On PKP 0 1 1 FC103 0
40669 29C Trigger On Trip 0 1 1 FC103 0
40670 29D Trigger On Alarm 0 1 1 FC103 0
40671 29E Trigger on DPO 0 1 1 FC103 0
40672 29F Trace Memory Channel Selector 0 16 1 F26 0
40672 29F Trace Memory Channel Selector 0 16 1 F26B 0
40673 2A0 Trace Memory Buffer Selector 0 10 1 F1 0
40674 2A1 Trace Memory Sample Index 0 6144 1 F1 0
40675 2A2 Trigger Source 1 0xD002 1 FC133 1
40676 2A3 Trigger Position 0 100 1 F1 20
40677 2A4 Trigger Mode 0 1 1 FC148 0
40678 2A5 Transient Buffer Setup 0 2 1 F95 0
RELAY STATUS
40927 39E Relay Status 0 1 1 F99 0
CONTACT INPUT NAMES (1 - 8)
40961 3C0 Input Name 1 0 9 1 F22 27
40970 3C9 Input Name 2 0 9 1 F22 28
40979 3D2 Input Name 3 0 9 1 F22 29
40988 3DB Input Name 4 0 9 1 F22 30
40997 3E4 Input Name 5 0 9 1 F22 31
41006 3ED Input Name 6 0 9 1 F22 32
41015 3F6 Input Name 7 0 9 1 F22 33
41024 3FF Input Name 8 0 9 1 F22 34
EDIT SETPOINT GROUP
41113 458 Edit Setpoint Group -1 1 1 F91 0
LOGIC ELEMENTS
41118 45D Timer 1 Pickup Delay 0 6000 1 F1 0
41119 45E Timer 1 Dropout Delay 0 6000 1 F1 0
41120 45F LE 1 Function 0 4 1 FC205 0
41121 460 LE 1 Asserted 0 1 1 FC103 0
41122 461 LE 1 Relays 0 0x7F 1 FC198 0
41126 465 Timer 2 Pickup Delay 0 6000 1 F1 0
41127 466 Timer 2 Dropout Delay 0 6000 1 F1 0
41128 467 LE 2 Function 0 4 1 FC205 0
41129 468 LE 2 Asserted 0 1 1 FC103 0
41130 469 LE 2 Relays 0 0x7F 1 FC198 0
41134 46D Timer 3 Pickup Delay 0 6000 1 F1 0
41135 46E Timer 3 Dropout Delay 0 6000 1 F1 0
41136 46F LE 3 Function 0 4 1 FC205 0
41137 470 LE 3 Asserted 0 1 1 FC103 0
41138 471 LE 3 Relays 0 0x7F 1 FC198 0
41142 475 Timer 4 Pickup Delay 0 6000 1 F1 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
