CHAPTER 6: SETPOINTS S4 CONTROLS
350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 6–127
Phase Instantaneous
Overcurrent
Ph IOC1 Trip PKP Ph IOC1 Alarm PKP Ph IOC2 Trip DPO
Ph IOC1 Trip OP Ph IOC1 Alarm OP Ph IOC1 Block
Ph IOC1 Trip DPO Ph IOC1 Alarm DPO Ph IOC2 Alarm DPO
Ph IOC2 Trip PKP Ph IOC2 Alarm PKP Ph IOC2 Block
Ph IOC2 Trip OP Ph IOC2 Alarm OP
Ph A IOC1 Alrm PKP Ph A IOC1 Trip PKP Ph A IOC2 Alrm PKP
Ph A IOC1 Alrm OP Ph A IOC1 Trip OP Ph A IOC2 Alrm OP
Ph A IOC1 Alrm DPO Ph A IOC1 Trip DPO Ph A IOC2 Alrm DPO
Ph B IOC1 Alrm PKP Ph B IOC1 Trip PKP Ph B IOC2 Alrm PKP
Ph B IOC1 Alrm OP Ph B IOC1 Trip OP Ph B IOC2 Alrm OP
Ph B IOC1 Alrm DPO Ph B IOC1 Trip DPO Ph B IOC2 Alrm DPO
Ph C IOC1 Alrm PKP Ph C IOC1 Trip PKP Ph C IOC2 Alrm PKP
Ph C IOC1 Alrm OP Ph C IOC1 Trip OP Ph C IOC2 Alrm OP
Ph C IOC1 Alrm DPO Ph C IOC1 Trip DPO Ph C IOC2 Alrm DPO
Ph A IOC2 Trip PKP Ph B IOC2 Trip PKP Ph C IOC2 Trip PKP
Ph A IOC2 Trip OP Ph B IOC2 Trip OP Ph C IOC2 Trip OP
Ph A IOC2 Trip DPO Ph B IOC2 Trip DPO Ph C IOC2 Trip DPO
Element Operands
