CHAPTER 6: METERING FLEXELEMENTS
845 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL 6–21
FlexElements
Path: Metering > FlexElements
The operating signals for the FlexElements are displayed in pu values using the definitions
of the base units in the Definitions of the Base Unit for the FLEXELEMENT table. This table is
in the Setpoints>FlexLogic>FlexElements section.
FlexElement Operating Signals:
FlexEI 1 Op Signal
FlexEI 2 Op Signal
FlexEI 3 Op Signal
FlexEI 4 Op Signal
FlexEI 5 Op Signal
FlexEI 6 Op Signal
FlexEI 7 Op Signal
FlexEI 8 Op Signal
