GE ACT17CWA - Page 19

18
C
B
A
red
yellow
white
Wired Controller Wiring Instruction
Communication Wiring
*Ground only one end of the shielded cable
Wiring Diagrams
Communication wiring length (m/ft)
Wire Size
< 100m/328ft
0.3mm
2
x3-core shielded wire
(22AWG,3wire)
PIW DQG PIW
0.5mm
2
x3-core shielded wire
(20AWG,3wire)
PIW DQG PIW
0.75mm
2
x3-core shielded
wire (18AWG,3wire)
PIW DQG PIW
1.25mm
2
x3-core shielded wire
(16AWG,3wire)
PIW DQG PIW
2mm
2
x3-core shielded wire
(14AWG,3wire)
