GE APCD07 - Page 10

10 49-5000544 Rev. 1
INSTALLATION INSTRUCTIONS
Installation Instructions
1. Auto Swing Louver
2. Controls
3. Built-in Handle
&DVWHUV
5. Upper Filter Panel
6. Top Continuous Drain
7. Exhaust Vent
8. Lower Drain
/'&,3OXJ
&RUG:LQGHU
11. Lower Filter Panel
12. Power Cord
13. Remote Control
14. 2 AAA batteries
PARTS INCLUDED
(Appearance may vary)
1
2
3
4
8
7
5
6
9
10
11
12
3

Exhaust Hose Assembly
Remote Control
%DWWHULHV
Phillips head screwdriver
1RW,QFOXGHG
TOOLS YOU WILL NEED
Window Mounting Kit
1 pc – 20” Center Panel
SF±ï»๜´(QWHQVLRQ
1 pc – 9” Extension
2 pc – 16” Extensions
3RLQWHG6FUHZV
2 – Top Window Bracket
1 – Security Bracket
4 – Main Window Panel
Security Bracket%RWWRP:LQGRZ%UDFNHW7RS:LQGRZ%UDFNHW
Top Foam Strip
Bottom Foam Strip
Foam Strip
Flat Tip Screw
For exhaust nozzle to
main window panel.
