31-5000483 Rev. 2 08-20 GEA
Split Type Heat Pump
Installation
Instructions
READ CAREFULLY.
KEEP THESE INSTRUCTIONS
.
The manufacture recommends installing
AHRI listed matched indoor and outdoor
system. Installing approved matched indoor
and outdoor system will provide optimum
efficiency and best overall system reliability.
