2-114 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
B30, C60, F35,
L90, N60, T35,
T60
7750 ...Repeated for Disconnect Switch 17
" 7751 ...Repeated for Disconnect Switch 18
" 7752 ...Repeated for Disconnect Switch 19
" 7753 ...Repeated for Disconnect Switch 20
" 7754 ...Repeated for Disconnect Switch 21
" 7755 ...Repeated for Disconnect Switch 22
" 7756 ...Repeated for Disconnect Switch 23
" 7757 ...Repeated for Disconnect Switch 24
Thermal Overload Protection (Read/Write Settings) (2 Modules)
All except B90,
C30, M60
7788 Thermal Protection 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7789 Thermal Protection 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 778A Thermal Protection 1 Base Current 0.2 to 3 pu 0.01 F001 80
" 778B Thermal Protection 1 K Factor 1 to 1.2 --- 0.05 F001 110
" 778C Thermal Protection 1 Trip Time Constant 0 to 1000 min. 1 F001 45
" 778D Thermal Protection 1 Reset Time Constant 0 to 1000 min. 1 F001 45
" 778E Thermal Protection 1 Minimum Reset Time 0 to 1000 min. 1 F001 20
" 778F Thermal Protection 1 Reset 0 to 4294967295 --- 1 F300 0
" 7791 Thermal Protection 1 Block 0 to 4294967295 --- 1 F300 0
" 7793 Thermal Protection 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7794 Thermal Protection 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 7795 Reserved (2 items) --- --- --- F001 0
" 7797 Repeated for Thermal Protection 2
Broken Conductor Detection (Read/Write Settings) (2 or 6 Modules)
D30, D60, F35,
F60, L30, L60,
L90
77AA Broken Conductor 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 77AB Broken Conductor 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 77AC Broken Conductor 1 I2/I1 Ratio 20 to 100 % 0.1 F001 200
" 77AD Broken Conductor 1 I1 Minimum 0.05 to 1 pu 0.01 F001 10
" 77AE Broken Conductor 1 I1 Maximum 0.05 to 5 pu 0.01 F001 150
" 77AF Broken Conductor 1 Pickup Delay 0 to 65.535 s 0.001 F001 20000
" 77B0 Broken Conductor 1 Block 0 to 4294967295 --- 1 F300 0
" 77B2 Broken Conductor 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 77B3 Broken Conductor 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 77B4 Reserved (2 items) --- --- --- F001 0
" 77B6 ...Repeated for Broken Conductor 2
F35 77C2 ...Repeated for Broken Conductor 3
" 77CE ...Repeated for Broken Conductor 4
" 77DA ...Repeated for Broken Conductor 5
" 77E6 ...Repeated for Broken Conductor 6
Ohm Inputs (Read/Write Setting) (2 Modules)
All except B90 77F8 Ohm Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 77F9 Ohm Inputs 1 ID --- --- --- F205 "Ohm Ip 1 "
" 77FF Ohm Inputs 1 Reserved (9 items) 0 to 65535 --- 1 F001 0
" 7808 ...Repeated for Ohm Inputs 2
Products Address Register name Range Units Step Format Default
