2-146 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
Cold Load Pickup (Read/Write Setting) (2 or 6 Modules)
F35, F60 9F30 Cold Load Pickup 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 9F31 Cold Load Pickup 1 Initiate 0 to 4294967295 --- 1 F300 0
" 9F33 Cold Load Pickup 1 Block 0 to 4294967295 --- 1 F300 0
" 9F35 Outage Time Before Cold Load Pickup 1 0 to 1000 s 1 F001 1000
" 9F36 On Load Time Before Reset 1 0 to 1000000 s 0.001 F003 100000
" 9F38 Cold Load Pickup 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" 9F39 Cold Load Pickup 1 Reserved 0 to 65535 --- 1 F001 0
" 9F3A ...Repeated for Cold Load Pickup 2
F35 9F44 ...Repeated for Cold Load Pickup 3
" 9F4E ...Repeated for Cold Load Pickup 4
" 9F58 ...Repeated for Cold Load Pickup 5
" 9F62 ...Repeated for Cold Load Pickup 6
B90 Direct Outputs (Read/Write Setting) (256 Modules)
B90 A000 Direct Output 1 Operand 0 to 4294967295 --- 1 F300 0
" A002 Direct Output 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" A003 ...Repeated for Direct Output 2
" A006 ...Repeated for Direct Output 3
" A009 ...Repeated for Direct Output 4
" A00C ...Repeated for Direct Output 5
" A00F ...Repeated for Direct Output 6
" A012 ...Repeated for Direct Output 7
" A015 ...Repeated for Direct Output 8
" A018 ...Repeated for Direct Output 9
" A01B ...Repeated for Direct Output 10
... ...
" A093 ...Repeated for Direct Output 50
" A129 ...Repeated for Direct Output 100
... ...
" A1BF ...Repeated for Direct Output 150
... ...
" A255 ...Repeated for Direct Output 200
... ...
" A2FD ...Repeated for Direct Output 256
Broken Rotor Bar Detection (Read Only Actual Values)
M60 A020 Broken Rotor Bar Component Level –100 to 0 dB 0.1 F002 –1000
" A021 Broken Rotor Bar Component Frequency 0 to 76 Hz 0.01 F001 0
" A022 Motor Load at Broken Rotor Bar Calculation 0 to 1.5 × FLA 0.01 F001 0
" A023 Motor Load Deviation at Broken Rotor Bar
Calculation
0 to 1.5 × FLA 0.01 F001 0
" A024 Time Stamp at Broken Rotor Bar
Calculation
0 to 4294967295 --- 1 F050 0
" A026 Maximum Broken Rotor Bar Component
Level
–100 to 0 dB 0.1 F002 –1000
" A027 Maximum Broken Rotor Bar Component
Frequency
0 to 76 Hz 0.01 F001 0
" A028 Motor Load at Broken Rotor Bar Maximum 0 to 1.5 × FLA 0.01 F001 0
Products Address Register name Range Units Step Format Default
