2-154 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" A97E ...Repeated for Restricted Ground Fault 4
T35, T60 A988 ...Repeated for Restricted Ground Fault 5
" A992 ...Repeated for Restricted Ground Fault 6
IEC 61850 Received Analog Settings (Read/Write) (32 Modules)
All AA00 IEC 61850 GOOSE Analog 1 Default Value –1000000 to
1000000
--- 0.001 F060 1000
" AA02 IEC 61850 GOOSE Analog Input 1 Mode 0 to 1 --- 1 F491 0 (Default
Value)
" AA03 IEC 61850 GOOSE Analog Input 1 Units --- --- --- F207 (none)
" AA05 IEC 61850 GOOSE Analog Input 1 Per-Unit
Base
0 to 999999999.999 --- 0.001 F060 1
" AA07 ...Repeated for IEC 61850 GOOSE Analog
Input 2
" AA0E ...Repeated for IEC 61850 GOOSE Analog
Input 3
" AA15 ...Repeated for IEC 61850 GOOSE Analog
Input 4
" AA1C ...Repeated for IEC 61850 GOOSE Analog
Input 5
" AA23 ...Repeated for IEC 61850 GOOSE Analog
Input 6
" AA2A ...Repeated for IEC 61850 GOOSE Analog
Input 7
" AA31 ...Repeated for IEC 61850 GOOSE Analog
Input 8
" AA38 ...Repeated for IEC 61850 GOOSE Analog
Input 9
" AA3F ...Repeated for IEC 61850 GOOSE Analog
Input 10
" AA46 ...Repeated for IEC 61850 GOOSE Analog
Input 11
" AA4D ...Repeated for IEC 61850 GOOSE Analog
Input 12
" AA54 ...Repeated for IEC 61850 GOOSE Analog
Input 13
" AA5B ...Repeated for IEC 61850 GOOSE Analog
Input 14
" AA62 ...Repeated for IEC 61850 GOOSE Analog
Input 15
" AA69 ...Repeated for IEC 61850 GOOSE Analog
Input 16
" AA70 ...Repeated for IEC 61850 GOOSE Analog
Input 17
" AA77 ...Repeated for IEC 61850 GOOSE Analog
Input 18
" AA7E ...Repeated for IEC 61850 GOOSE Analog
Input 19
" AA85 ...Repeated for IEC 61850 GOOSE Analog
Input 20
" AA8C ...Repeated for IEC 61850 GOOSE Analog
Input 21
" AA93 ...Repeated for IEC 61850 GOOSE Analog
Input 22
" AA9A ...Repeated for IEC 61850 GOOSE Analog
Input 23
Products Address Register name Range Units Step Format Default
