GE b30 - 5.6 GROUPED ELEMENTS

3-34 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
Table 3-13: GOOSE subscription monitor (LGOS)
LGOS is instantiated in all UR family devices.
See the G2 implementation model for GOOSE configuration via SCL
section on page 3-232 for descriptions of data objects
MAC, APPID, GoDatSetRef, GoID, ConfRev and InRefδδ.
Table 3-14: GOOSE subscription monitor data objects
RxGooseOf
f
SPS RxGOOSE OFF operand R
stVal BOOLEAN ST RxGOOSE OFF R
RrtdComFa
il
SPS RRTD COMM FAIL operand R
stVal BOOLEAN ST RRTD COMM FAIL R
SecEthFail SPS SECOND ETHERNET FAIL operand R
stVal BOOLEAN ST SECOND ETHERNET FAIL R
LNName: LPHD1LDevice inst: MasterUR element:
data obj. data attribute Type FC UR Name Description R/W/C
ThrdEthFail SPS THIRD ETHERNET FAIL operand R
stVal BOOLEAN ST THIRD ETHERNET FAIL R
SntpFail SPS SNTP FAILURE operand R
stVal BOOLEAN ST SNTP FAILURE R
SysExcp SPS SYSTEM EXCEPTION operand R
stVal BOOLEAN ST SYSTEM EXCEPTION R
TempMnt SPS TEMP MONITOR operand R
stVal BOOLEAN ST TEMP MONITOR R
UNotPrgm SPS UNIT NOT PROGRAMMED operand R
stVal BOOLEAN ST UNIT NOT PROGRAMMED R
ProcBusFai
l
SPS PROCESS BUS FAILURE operand R
stVal BOOLEAN ST PROCESS BUS FAILURE R
ProcBusTr
b
l
SPS PROCESS BUS TROUBLE operand R
stVal BOOLEAN ST PROCESS BUS TROUBLE R
VoltMntr SPS VOLTAGE MONITOR operand R
stVal BOOLEAN ST VOLTAGE MONITOR R
BrckTrbl SPS BRICK TROUBLE operand R
stVal BOOLEAN ST BRICK TROUBLE R
RtdTrbl SPS RTD TROUBLE operand R
stVal BOOLEAN ST RTD TROUBLE R
TdrTrbl SPS TDR TROUBLE operand R
stVal BOOLEAN ST TDR TROUBLE R
InRef1 ORG PROCESS BUS FAILURE setting. R
setSrcRef ObjectReference SP PROCESS BUS FAILURE setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: LGOS#LDevice inst: MasterUR element: Mapped to setting RxGOOSE# ID if not empty string,
data obj. data attribute Type FC UR Name Description R/W/C
St SPS RxGOOSE# On operand R
stVal BOOLEAN ST RxGOOSE# On R
Alm SPS RxGOOSE# Off operand R
stVal BOOLEAN ST RxGOOSE# Off R
LNName: LPHD1LDevice inst: MasterUR element:
data obj. data attribute Type FC UR Name Description R/W/C
